Product Introduction

Shell and Tube Heat Exchanger

Shell and tube heat exchangers are the most widely used heat transfer equipment in petroleum refining, chemical plants and oil & gas processing. They consist of a cylindrical shell, a bundle of tubes inside, tube sheets, baffles and channels. One fluid flows inside the tubes while the other passes through the shell side around the tubes, enabling efficient heat exchange without mixing.

With advantages of high pressure resistance, good thermal efficiency, strong adaptability and easy maintenance, they are widely applied in heating, cooling, condensation and evaporation processes. In refineries, they are used in crude preheating, product cooling, heat recovery and energy saving systems, effectively improving unit energy efficiency and ensuring stable operation of process units.

Types and Characteristics of Equipment

Type

Type: Fixed tube-sheet, floating-head and U-tube heat exchangers (main equipment for refinery export)

Features

Resistant to high pressure and high temperature, suitable for heat exchange of oil products, oil gas and hydrogen.Sturdy structure, reliable operation and convenient maintenance.High heat transfer efficiency and excellent energy-saving effect.Compliant with ASME and GB standards.

Heat Exchanger

It helps recover waste heat, reduce energy consumption and stabilize process temperatures.

Heat Exchanger

A heat exchanger efficiently transfers thermal energy between two or more fluids without mixing them.

Heat Exchanger

It is widely used in refineries, petrochemical plants and HVAC systems for energy saving.

Basic Principles and System Composition

Basic Working Principle

One medium flows inside the tube bundle (tube side), while the other flows between the tube bundle and the shell (shell side). Heat is exchanged through the tube walls, cooling the hot fluid and heating the cold fluid.

Overall System Composition

Shell Tube bundle and heat exchange tubes Channel head, head cover Baffle plate Tube sheet, flange

Basic Principles and System Composition

Hot and cold media enter the tube side and shell side respectively. Heat exchange occurs through counter-current flow of the media. The hot fluid releases heat and cools down, while the cold fluid absorbs heat and heats up. The two media are discharged separately to realize continuous heat exchange.
